Used Haitian 380 Ton MA3800Ⅲ/2250 Injection Molding Machine

Item No. C-H-028HaitianYear 2022China

Used 380-ton Haitian MA3800Ⅲ/2250 injection molding machine, 70mm B-screw, ideal for mass-producing extra-large thick-wall household, appliance, automotive and industrial plastic parts.

Request a QuoteSpecification PDF

Specifications

Item Number: C-H-028
Brand: Haitian
Model: MA3800Ⅲ/2250
Year: 2022
Location: Dongguan City, China
Screw Diameter (mm): 70
Injection Weight (PS) (g): 1128
Injection Rate (PS) (g/s): 337
Clamping Force (kN): 3800
Dist. Between Tie Bars (H x V) (mm): 730×730
Machine Dimension (L x W x H) (m): 7.5×1.8×2.3
Machine Weight (t): 14.7

Tonnage Range: 300-500T

Why This Machine

Haitian MA3800Ⅲ/2250 delivers 380-ton clamping force with 730×730mm tie bar spacing and up to 1473g shot weight (C-screw). Its servo-hydraulic system ensures energy savings and stable production—ideal for automotive parts, large household goods, and industrial components requiring reliable heavy-duty molding capacity.

Description

Pre-owned Haitian MA3800III/2250 injection molding machine with 70 mm B-screw. 3800 kN clamping force, 1239 cm³ shot volume, 1128 g PS shot weight, 183 MPa injection pressure, 730×730 mm tie bars, 280–730 mm mold thickness, 110 kN ejector force.
