Used Haitian 250 Ton MA2500/1000G Injection Molding Machine

Item No. Z-H-002HaitianYear 2016China

Used 250‑ton Haitian MA2500/1000G injection molding machine with 55mm B‑spec screw. Ideal for mass‑producing medium‑large household, electronic, automotive and general industrial plastic parts.

Request a QuoteSpecification PDF

Specifications

Item Number: Z-H-002
Brand: Haitian
Model: MA2500/1000G
Year: 2016
Location: Dongguan City, China
Screw Diameter (mm): 55
Injection Weight (PS) (g): 547
Injection Rate (PS) (g/s): 210
Clamping Force (kN): 2500
Dist. Between Tie Bars (H x V) (mm): 570×570
Machine Dimension (L x W x H) (m): 5.76×1.46×2.15
Machine Weight (t): 7.5

Tonnage Range: 100-300T

Why This Machine

The Haitian MA2500/1000G delivers reliable 250-ton clamping force with precise injection control, ideal for demanding production. Its energy-efficient servo system cuts power costs while maintaining high repeatability. Built for durability and easy maintenance, this machine maximizes uptime and ROI—a smart, proven choice for your molding needs.

Description

Used Haitian MA2500/1000G injection molding machine with 55 mm B-spec screw. 2500 kN clamping force, 601 cm³ shot volume, 547 g shot weight, 169 MPa injection pressure, 570×570 mm tie bars, 220–570 mm mold thickness, 62 kN ejector force.
