Used 800 Ton JM800‑C3‑SVP2 Injection Molding Machine

Item No. Z-Z-021Chen HsongYear 2023China

Used JM800‑C3‑SVP2 injection molding machine,800‑ton clamp force with triple‑screw options for mass‑producing ultra‑large heavy‑duty plastic parts.

Request a QuoteSpecification PDF

Specifications

Item Number: Z-Z-021
Brand: CHEN HSONG
Model: JM800‑C3‑SVP2
Year: 2023
Location: Dongguan City, China
Screw Diameter (mm): 98
Injection Weight (PS) (g): 3191
Injection Rate (PS) (g/s): 554
Clamping Force (kN): 8000
Dist. Between Tie Bars (H x V) (mm): 1000×1000
Machine Dimension (L x W x H) (m): 11.2×2.4×2.3
Machine Weight (t): 34.5

Tonnage Range: 500-1000T

Why This Machine

The JM800-C3-SVP2 injection molding machine features 800-ton clamping force, three screw options (90/98/110 mm), and PS shot weights up to 4,021 g. Ideal for large household plastics, oversized furniture components, electronic enclosures, automotive parts, industrial containers. We offer inspection reports, financing, and worldwide shipping.

Description

Used JM800-C3-SVP2 injection molding machine with three screw options (90/98/110 mm) and 800-ton clamping force. PS shot weight ranges from 2,692g to 4,021g, with injection pressure up to 2,180 kgf/cm². Featuring 1000×1000 mm tie-bar spacing and 400–1075 mm mould thickness, it is suitable for producing large household plastics, electronic housings, automotive parts, packaging, and heavy-duty industrial components.
