Used 408 Ton JM408‑MK6.6/A Injection Molding Machine

Item No. Z-Z-019Chen HsongYear 2023China

Used JM408‑MK6.6/A injection molding machine,408‑ton clamp force with triple‑screw options for mass‑producing extra‑large plastic parts.

Request a QuoteSpecification PDF

Specifications

Item Number: Z-Z-019
Brand: CHEN HSONG
Model: JM408‑MK6.6/A
Year: 2023
Location: Dongguan City, China
Screw Diameter (mm): 75
Injection Weight (PS) (g): 1506
Injection Rate (PS) (g/s): 399
Clamping Force (kN): 4080
Dist. Between Tie Bars (H x V) (mm): 730×730
Machine Dimension (L x W x H) (m): 7.8×1.8×2.3
Machine Weight (t): 17.5

Tonnage Range: 300-500T

Why This Machine

The JM408-MK6.6/A injection molding machine features 408-ton clamping force, three screw options (67/75/83 mm), and PS shot weights up to 1,845 g. Ideal for large household plastics, electronic components, automotive parts, heavy-duty packaging, and large industrial components. We offer inspection reports, financing, and worldwide shipping.

Description

Used JM408-MK6.6/A injection molding machine with three screw options (67/75/83 mm) and 408-ton clamping force. PS shot weight ranges from 1,202g to 1,845g, with injection pressure up to 2,230 kgf/cm². Featuring 730×730 mm tie-bar spacing and 250–730 mm mould thickness, it is suitable for producing household plastics, electronic housings, automotive parts, packaging, and large industrial components.
