Used 328 Ton JM328‑MK6.6/C Injection Molding Machine

Item No. Z-Z-018Chen HsongYear 2022China

Used JM328‑MK6.6/C injection molding machine,328‑ton clamp force with triple‑screw options for mass‑producing large‑size plastic parts.

Request a QuoteSpecification PDF

Specifications

Item Number: Z-Z-018
Brand: CHEN HSONG
Model: JM328‑MK6.6/C
Year: 2022
Location: Dongguan City, China
Screw Diameter (mm): 67
Injection Weight (PS) (g): 1074
Injection Rate (PS) (g/s): 395
Clamping Force (kN): 3280
Dist. Between Tie Bars (H x V) (mm): 660×660
Machine Dimension (L x W x H) (m): 6.7×1.7×2.4
Machine Weight (t): 14.5

Tonnage Range: 300-500T

Why This Machine

The JM328-MK6.6/C injection molding machine features 328-ton clamping force, three screw options (60/67/75 mm), and PS shot weights up to 1,346 g. Ideal for large household plastics, electronic components, automotive parts, heavy-duty packaging, and medium-to-large industrial components. We offer inspection reports, financing, and worldwide shipping.

Description

Used JM328-MK6.6/C injection molding machine with three screw options (60/67/75 mm) and 328-ton clamping force. PS shot weight ranges from 861g to 1,346g, with injection pressure up to 2,263 kgf/cm². Featuring 660×660 mm tie-bar spacing and 220–660 mm mould thickness, it is suitable for producing household plastics, electronic housings, automotive parts, packaging, and medium-to-large industrial components.
