Used 1000 Ton JM1000-C3-SVP2 Injection Molding Machine

Item No. Y-Z-0014Chen HsongYear 2021China

Used JM1000-C3-SVP2 injection molding machine,1000-ton clamp force with triple-screw options for mass-producing large-size heavy-duty plastic parts

Request a QuoteSpecification PDF

Specifications

Item Number: Y-Z-0014
Brand: CHEN HSONG
Model: JM1000-C3-SVP2
Year: 2021
Location: Dongguan City, China
Screw Diameter (mm): 110
Injection Weight (PS) (g): 4546
Injection Rate (PS) (g/s): 752
Clamping Force (kN): 10000
Dist. Between Tie Bars (H x V) (mm): 1100×1100
Machine Dimension (L x W x H) (m): 11.8×2.4×2.5
Machine Weight (t): 52

Tonnage Range: 500-1000T

Why This Machine

The JM1000-C3-SVP2 is a heavy-duty injection molding machine featuring 1,000-ton clamping force and three screw options (98/110/120 mm), with PS shot weights up to 5,411 g. Ideal for large household plastics, industrial enclosures, automotive parts, packaging, and engineering components. We offer detailed inspection reports, financing options, and worldwide shipping.

Description

Used JM1000-C3-SVP2 injection molding machine with three screw options (98/110/120 mm) and 1,000-ton clamping force. PS shot weight ranges from 3,608g to 5,411g, with maximum injection pressure up to 2,140 kgf/cm². Featuring 1100×1100 mm tie-bar spacing and 450–1200 mm mould thickness, it is suitable for producing large household plastics, electronic housings, automotive parts, packaging, and heavy-duty industrial components.
