Used 560 Ton EM560-SVP-2 Injection Molding Machine

Item No. Y-Z-0011Chen HsongYear 2015China

Used EM560-SVP-2 injection molding machine,560-ton clamping force with triple-screw options for mass-producing large-size heavy-duty plastic parts

Request a QuoteSpecification PDF

Specifications

Item Number: Y-Z-0011
Brand: CHEN HSONG
Model: EM560-SVP-2
Year: 2015
Location: Dongguan City, China
Screw Diameter (mm): 83
Injection Weight (PS) (g): 1990
Injection Rate (PS) (g/s): 494
Clamping Force (kN): 4800
Dist. Between Tie Bars (H x V) (mm): 855×855
Machine Dimension (L x W x H) (m): 9×2×2.3
Machine Weight (t): 20

Tonnage Range: 500-1000T

Why This Machine

The EM560-SVP-2 is a powerful injection molding machine featuring 560-ton clamping force and three screw options (75/83/90 mm). Ideal for large household plastics, electronic housings, automotive components, packaging, and industrial parts. We offer detailed inspection reports, financing options, and worldwide shipping.

Description

Used EM560-SVP-2 injection molding machine with three screw options (75/83/90 mm) and 560-ton clamping force. PS shot weight ranges from 1,625g to 2,340g, with maximum injection pressure up to 2,131 kgf/cm². Featuring 855×855 mm tie-bar spacing and 330–850 mm mould height, it is suitable for producing household plastics, electronic housings, automotive parts, packaging, and heavy-duty industrial components.
