Used 320 Ton EM320-SVP-2 Injection Molding Machine

Item No. Y-Z-009Chen HsongYear 2015China

Used EM320-SVP-2 injection molding machine,320-ton clamping force with triple-screw options for mass-producing medium-large plastic parts.

Request a QuoteSpecification PDF

Specifications

Item Number: Y-Z-009
Brand: CHEN HSONG
Model: EM320-SVP-2
Year: 2015
Location: Dongguan City, China
Screw Diameter (mm): 67
Injection Weight (PS) (g): 1038
Injection Rate (PS) (g/s): 305
Clamping Force (kN): 3200
Dist. Between Tie Bars (H x V) (mm): 660×660
Machine Dimension (L x W x H) (m): 6.9×1.6×2.3
Machine Weight (t): 10.6

Tonnage Range: 300-500T

Why This Machine

The EM320-SVP-2 is a versatile injection molding machine featuring 320-ton clamping force and three screw options (60/67/75 mm). Ideal for household plastics, electronic housings, automotive interior parts, packaging, and industrial components. We offer detailed inspection reports, financing options, and worldwide shipping.

Description

Used EM320-SVP-2 injection molding machine with three screw options (60/67/75 mm) and 320-ton clamping force. PS shot weight ranges from 832g to 1,300g, with maximum injection pressure up to 2,233 kgf/cm². Featuring 660×660 mm tie-bar spacing and 220–660 mm mould thickness, it is suitable for producing household plastics, electronic housings, automotive parts, packaging, and industrial components.
